主要技術參數
反饋信號：4-20mA D.C或0-10mA D.C
輸入電阻：Ⅲ250ΩⅡ200Ω
輸入通道：3個
電源電壓：220V +10%/-15% 50HZ±1%
使用環境溫度：-25～＋70 oC

使用環境濕度：≤95 oC

DKJ執行器主要分類：
1：普通角行程電動執行機構（含遠控型）型號有：

DKJ-210CX，DKJ-310CX，DKJ-410CX，DKJ-510CX，DKJ-610CX，DKJ-710CX

DKJ-210，DKJ-310，DKJ-410，DKJ-510，DKJ-610AM，DKJ-610

DKJ-2100，DKJ-3100，DKJ-4100，DKJ-5100，DKJ-6100AM，DKJ-6100

DKJ-2100M，DKJ-3100M，DKJ-4100M，DKJ-5100M，DKJ-6100AM，DKJ-7100M

DKJ-2100W，DKJ-3100W，DKJ-4100W，DKJ-5100W，DKJ-6100AM，DKJ-7100W

2：電子式角行程電動執行機構型號有：

DKJ-2100D，DKJ-3100D，DKJ-4100D，DKJ-5100D，DKJ-6100AM，DKJ-7100D

3：直聯式角行程電動執行機構

DKJ-210Z，DKJ-310Z，DKJ-410Z，DKJ-510Z、DKJ-610Z，DKJ-710Z

DKJ-2100Z，DKJ-3100Z，DKJ-4100Z，DKJ-5100Z，DKJ-6100Z，DKJ-7100Z

4：防爆型角行程電動執行機構 防爆等級：dIIBT3

DKJ-210B，DKJ-310B，DKJ-410B、 DKJ-510B，DKJ-610B，DKJ-710B

DKJ-2100B，DKJ-3100B，DKJ-4100B、 DKJ-5100B，DKJ-6100B，DKJ-7100B

DKJ-210EX，DKJ-310 EX，DKJ-410 EX、 DKJ-510 EX，DKJ-610 EX，DKJ-710 EX

5：ZKJ角行程電動執行機構產品型號：普通型

ZKJ-2100，ZKJ-3100，ZKJ-4100，ZKJ-5100，ZKJ-6100，ZKJ-7100

ZKJ-210AM，ZKJ-3100AM，ZKJ-4100AM，ZKJ-5100AM，ZKJ-6100AM，ZKJ-7100AM

6：智能型一體化角行程SKJ電動執行機構：

SKJ-210，SKJ-310，SKJ-410，SKJ-510，SKJ-610，SKJ-710

SKJ-2100Z，SKJ-3100Z，SKJ-4100Z，SKJ-5100Z，SKJ-6100Z，SKJ-7100Z

SKJ-2100M，SKJ-3100M，SKJ-4100M，SKJ-5100M，SKJ-6100M，SKJ-7100M
